CUBE FOLD HYBRID 500 MERLOTRED/REFLEX
CUBE FOLD HYBRID 500 MERLOTRED/REFLEX
Plus Points
- High-quality aluminum frame
- Practical and sturdy folding mechanism
- Bosch Performance motor
- Height-adjustable handlebars and saddle
- With practical handle
- Includes fenders, stable kickstand, lock, and rear rack
- Optional front rack and matching bags
Advisory points
- Less maintenance-friendly than the Fold Hybrid Comfort with hub gears and belt drive
- Larger wheels roll better
Description
Frame description
When we set out to design our foldable Bosch e-bike, we wanted it to set new standards for flexibility, mobility and functionality. The fact that it also looks great is no coincidence, because form often follows function. With its clever folding mechanism and integrated carry handle, the Fold Hybrid is easy to store or transport in an efficient, space-saving size and shape. Simple saddle and handlebar adjustments mean it's quick to set up for almost any rider height. We included mudguards, a really stable kickstand and a sturdy rear carrier. And an optional front carrier – plus a wide range of bags and baskets that attach quickly and simply via innovative mechanisms – make it simple to carry whatever you need along for the ride. You'll wonder how you ever managed without it.
Calculate your size!
Fill in your height and inseam below and click 'Calculate my frame size' to see what size you need. Measure your inseam as follows:
- Stand barefoot with your heels against the wall. Place your feet about 15 centimeters apart.
- Grab a book and place it between your legs, with the short side of the book against the wall. Press the book upward against your crotch, mimicking the idea of a bicycle seat.
- Measure the length from the top of the book to the ground, the distance you measure is your inseam.
Product specifications
Frame
Model code
820210
Model year
2025
Colour
merlotred/reflex
Fork
Cube Aluminium Rigid Fork, 20"
E-bike System
Engine
Bosch Drive Unit Active Plus Generation 3 (50Nm) Cruise (250Watt)
Battery
Bosch PowerPack 500
display
Bosch Purion
Drivetrain and brakes
Front brake
Shimano BR-MT200, Hydr. Disc Brake (180/180)
Rear brake
Shimano BR-MT200, Hydr. Disc Brake (180/180)
Rear derailleur
Shimano Tiagra RD-4700GS, 10-Speed
Shifters
Shimano Tiagra SL-4700
Crankset
Acid Trekking Hybrid, 42T with Chainguard
Cassette
Shimano CS-HG500, 11-34T
Chain
KMC X10
Cockpit
Headset
Acros AZF-1038 Zero-Stack 1 1/8" (ZS 44mm), Bottom Zero-Stack 1 1/2" (ZS 56mm)
Handlebar
Cube Comfort Trail Bar, 680mm, 25.4mm
Stem
Cube Folding Stem, Adjustable Length, 25,4mm Clamp
Bar tape or grips
Acid Travel Comfort
Wheels
Rims
Cube EX30, 32H, Disc, Tubeless Ready
Front hub
Shimano HB-QC300, QR, Centerlock
Rear Hub
Shimano FH-QC300-HM, QR, Centerlock
Front tyre
Schwalbe Super Moto-X, Double Defense, 62-406
Rear Tyre
Schwalbe Super Moto-X, Double Defense, 62-406
Other parts
Saddle
Sequence
Seatpost
Satori Sorata 34.9mm, 280mm -440mm telescoping seatpost
Pedals
Cube Folding Pedal, Aluminium
Front light
Acid PRO-E 60, 12V, DC
Rear light
Acid Mudguard Rear Light PRO-E, 12V, DC
Kickstand
Cube Two Leg Kickstand
Mudguards
Acid 75, BB-Mount
Bell
Cube Easy Bell
Carrier
Acid 20" Semi-Integrated Carrier, RILink Adapter Compatible
