CUBE KATHMANDU HYBRID EXC 800 LIZARD/JUNIPER

CUBE KATHMANDU HYBRID EXC 800 LIZARD/JUNIPER

  • 812510
  • 812512
  • 812512_D_00
  • 812512_D_01
  • 812512_D_02
  • 812512_D_03
  • 812512_D_04
  • 812512_P_00
  • 812510_D_00
  • 812510_D_01
  • 812510_D_02
  • 812510_D_03
  • 812510_D_04
  • 812510_P_00
1 14
Choose your size or use our size guide.
£3,599.00
£3,599.00
Sale Sold out
Tax included.
  • Bikes mounted & delivered for free
  • 20 years of experience
  • Physical store for advice, service & maintenance
View full details
Description Specifications

Plus Points

  • Light yet strong Superlite-aluminium frame
  • New Bosch CX drive unit
  • New, extra-large 800 Wh Bosch PowerTube battery
  • Fast yet comfortable Efficient Comfort geometry
  • Shimano XT 12-speed
  • Shimano XT disc brakes
  • Thru-axles front and rear
  • Stiff integrated luggage rack
  • Fast yet comfortable tires
  • High-quality Fox suspension fork with air suspension
  • Suspension seat post
  • UDH rear dropouts
  • Available with classic frame, trapeze frame, or easy-entry frame

Advisory points

  • Slightly heavier than the SLX and SLT versions

Description

The Kathmandu Hybrid EXC 800 is designed to take you any Where. We started with a frame featuring our renowned Efficient Comfort Geometry, developed around a suspension fork with 100 millimeters of comfortable travel. Inside the frame, you'll find the new, lighter Bosch CX motor with 85 newton meters of torque and a PowerTube battery with a generous 800 Wh capacity. There’s also a beautiful and sturdy integrated IC 3.0 luggage rack. For its wide range and reliable performance, we chose Shimano's famous 12-speed XT transmission. The hydraulic disc brakes also carry the XT label, ensuring you can always and safely slow down, no matter the conditions. The bike is further equipped with a high-quality suspension fork from Fox – the 34 AWL Sport. And that’s not all; it also features an adjustable stem, a suspension seat post, and a complete set of accessories to finish it off.

From July 2025, CUBE bikes with the Bosch CX motor (BDU384Y) will get a significant performance boost. The upgrade can be easily installed by yourself via the Bosch eBike Flow App. No further actions are required.

With the eBike Flow App, you can increase the specifications of the Bosch motor to:
  • 100 Nm torque (90 Nm for models with a gear hub)
  • 750 W peak power
  • 400% support
Read more

Product specifications

Frame

  • Model year

    2025

  • Fork

    Fox 34 Float Sport AWL , Tapered, 15x110mm, E-Bike Optimized, 100mm

    • E-bike System

  • Engine

    Bosch Performance Line CX Generation 5 (BDU38) 85Nm, from July 2025 up to 100Nm, Smart System

  • Battery

    Bosch PowerTube 800

  • display

    Bosch Kiox 500

    • Drivetrain and brakes

  • Front brake

    Shimano XT BR-M8120, Hydr. Disc Brake (180/180)

  • Rear brake

    Shimano XT BR-M8120, Hydr. Disc Brake (180/180)

  • Rear derailleur

    Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed

  • Shifters

    Shimano Deore SL-M6100-IR, Direct Attach

  • Crankset

    Acid MTB Hybrid Pro

  • Cassette

    Shimano Deore CS-M6100, 10-51T

  • Chain

    KMC e12

    • Cockpit

  • Headset

    Acros AZF-1035, ICR (Integrated Cable Routing) Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), HIC

  • Handlebar

    Cube Comfort Trail Bar, 700mm

  • Stem

    Cube Comfort Stem Pro, 31.8mm, Adjustable

  • Bar tape or grips

    Acid Travel Comfort

    • Wheels

  • Wheels

    Cube EX25, 32H, Disc, Tubeless Ready

  • Rims

    Cube EX25, 32H, Disc, Tubeless Ready

  • Front hub

    Cube Engineered By Newmen, 15mm, Boost, Centerlock

  • Rear Hub

    Cube Engineered By Newmen, 12mm, Boost, Centerlock

  • Front tyre

    Schwalbe Energizer Plus, Performance, Green Guard, 55-622

  • Rear Tyre

    Schwalbe Energizer Plus, Performance, Green Guard, 55-622

    • Other parts

  • Saddle

    Acid Sequence Pro Plus

  • Seatpost

    Cube Suspension Seatpost HD, 31.6mm

  • Pedals

    Acid PP MTB

  • Front light

    Acid Front Light PRO-E 150 X-Connect, 12V, DC

  • Rear light

    Acid Mudguard Rear Light PRO-E, 12V, DC

  • Kickstand

    Acid FM Pure Kickstand

  • Mudguards

    Acid 65 Integrated Carrier 3.0

  • Bell

    Cube Easy Bell

  • Carrier

    Acid Integrated Carrier 3.0, Adapter Compatible
