What does frame type mean for CUBE bikes? For sporty bikes, such as road bikes and mountain bikes, the frame type is always unisex, even if there are k. Here, it's all about performance, sizing, and adjustability. CUBE offers models for everyone, with unisex geometry.
Size
?
What does frame type mean for CUBE bikes? For sporty bikes, such as road bikes and mountain bikes, the frame type is always unisex, even if there are k. Here, it's all about performance, sizing, and adjustability. CUBE offers models for everyone, with unisex geometry.
Minder is meer. In dit geval minder gewicht, wat is bij kinderfietsen altijd beter is. Om die reden hebben we een starre aluminium voorvork in de CUBE Acid 240 SL gehangen. Die weegt niet alleen veel minder, maar stuurt ook nog eens snaarstrak. Ook strak: de soepele Shimano 9-speed aandrijflijn met een 42-tands klimverzet. En krachtige V-brakes met kleinere remhendels. We hebben zelfs gedacht aan dunnere handvatten, zodat ook kleinere handende fiets altijd en overal onder controle houden.
Read more
Matching accessories
CUBE Bottle Cage Hpp-Sidecage Black/Blue
£16.95
CUBE KICKSTAND CM KID BIKES
£12.95
RFR Pedals Flat Hqp Cmpt Black
£14.95
Often bought together
CUBE Bottle Grip 0.5L Blue
£12.95
RFR CABLE LOCK HPS DOG 10 X 450 MM BLUE
£12.95
RFR SPOKE REFLECTOR SET PRO SILVER
£22.95
ACID LED LIGHT HPA WHITE LED BLACK
£19.95
ACID LED LIGHT HPA RED LED BLACK
£19.95
Acid Towingsystem Mountain Explorer Black
£29.95
Spare parts
CUBE MECH HANGER ACID & REACTION 200/240
£14.95
CUBE Touch Up Pen Set Vibrant Blue Glossy 2241
£19.95
CUBE Touch Up Pen Set Cool Grey 3 Glossy 2253
£19.95
CUBE HEADSET NUMBER 6 (ZS 1-1/8 - ZS 1-1/8)
£29.95
Specifications
General
Model code
423100
Model year
2022
Colour
teamline
Weight (kg)
?
Gewicht van fiets in maat M zonder pedalen. Grote en kleine maten kunnen lichter of zwaarder zijn: kleine frames hebben vaak minder materiaal → lichter.
9.5
Frame and front fork
Frame
Aluminium Lite 6061
Front fork
?
There are both suspension and rigid forks. For extra comfort while cycling, a suspension fork is the best choice. The fork material also varies. It can be made of aluminum, a combination of aluminum and carbon, or completely carbon.
Cube Rigid Alloy fork
Drivetrain and brakes
Number of gears
9
Rear derailleur
?
Brand and type of derailleur. The number of speeds indicates the number of sprockets.
Microshift RD-M619M, 9-Speed
Shifters
?
Make and type of gear levers.
Microshift SL-M9295, Xpress Shifter
Crankset
?
A crankset is the part of a bicycle that drives the pedals with the chain. It consists of cranks, chainrings and a bottom bracket.
Prowheel 32T, 140mm with Chainguard, Aluminium
Cassette
?
The set of gears on the back of the bicycle
Microshift CS-H093A, 11-42T
Chain
?
The bike can be driven in two ways; with a bike chain or with a belt drive. In the case of a belt it is always of the brand Gates.
KMC X9
Brake system front
?
Brand, type of brake system and diameter of the brake disc.
Cube Alloy V-Brake with Powermodulator
Brake system back
?
Brand, type of brake system and diameter of the brake disc.
Cube Alloy V-Brake with Powermodulator
Cockpit
Headset
?
The bearing mechanism in the bicycle frame in which the front fork rotates, allowing you to steer smoothly.
Cube A-Headset
Handlebar
Cube Aluminium, 580mm, 25.4
Stem
Cube Aluminium Lite
Wheels
Rims
Cube ACE17, 24H
Front hub
Cube Aluminium, QR
Rear hub
Cube Aluminium, QR
Front tyre
?
Front tire type, material and size where the first number is the width and the second number is the circumference in millimeters.
Schwalbe Billy Bonkers 2.0
Rear tyre
?
Rear tire type, material and size where the first number is the width and the second number is the circumference in millimeters.
Schwalbe Billy Bonkers 2.0
Other parts
Seat
Cube Kid
Seatpost
?
There are both sprung and fixed seatposts. For extra comfort while cycling, a sprung seatpost is the best choice.
Cube Aluminium Lite
Seatpost clamp
Cube Seatpost clamp
Pedals
?
The bike usually comes with pedals. If not, it is indicated here.
Cube Kid
Lakstift
?
Een lakstift is een snelle manier om kleine krasjes en steenslag op je fiets te herstellen. Een lakstift wordt niet standaard meegeleverd bij de fiets. Bestel hem apart via het artikelnummer hier rechts aangegeven. Het kan voorkomen dat er (nog) geen lakstift beschikbaar is.
