What does frame type mean for CUBE bikes? For sporty bikes, such as road bikes and mountain bikes, the frame type is always unisex, even if there are k. Here, it's all about performance, sizing, and adjustability. CUBE offers models for everyone, with unisex geometry.
Size
?
What does frame type mean for CUBE bikes? For sporty bikes, such as road bikes and mountain bikes, the frame type is always unisex, even if there are k. Here, it's all about performance, sizing, and adjustability. CUBE offers models for everyone, with unisex geometry.
World Champion Lucy Charles-Barclay had a lot of input into the development of the Aerium C:68X SLT. Partly as a result of this, the frame's premium C:68X® carbon construction incorporates flexible and adaptable hydration and storage options, including the ability to add up to two hydration systems for longer races. The CUBE cockpit puts everything you need at your fingertips, thanks to a wide range of adjustment. A Newmen Streem Aero 80/80 Vonoa wheelset – shod with Continental's Grand Prix 5000 TT tyres – is the perfect aero match for our wind tunnel-tested frame, giving you extra watts to translate into faster forward progress. And Shimano's inimitable Dura-Ace Di2 groupset – with 2x12 gearing, 4iiii power meter and hydraulic disc brakes – delivers precise shifts and controlled braking at race pace. Should you wish to revert to 1x gearing without a front derailleur, there's even a cover for the mounting area to preserve the frame's aero performance.
Frame description Developed in close collaboration with CUBE athlete and World Champion Lucy Charles-Barclay, the Aerium C:68X can rightly claim its title as the fastest frame we've ever made. Every detail, from the aero fork design, disc brake integration and in-frame hydration and storage systems, has been designed with zero compromise, tested in the wind tunnel and then tested again under pressure, in race conditions. That's why, for example, we fitted a high rise bar for the medium and large sizes – because seemingly small touches make a difference. Lucy has full confidence in the frame and its configurable storage and hydration, and now you can, too.
Read more
Matching accessories
New
ACID PEDALS CLICK ROAD C40 AERO SPD-SL COMPATIBLE BLACK
£99.95
New
ACID PEDALS CLICK ROAD P30 SPD-SL COMPATIBLE BLACK
£59.95
SHIMANO PEDALS PD-R7000 105 ROAD SPD-SL BLACK
£129.99
Often bought together
New
ACID LIGHT SET PRO 30 BLACK
£39.95
New
ACID LED LIGHT SET HPA BLACK
£39.95
New
ACID TUBE 28 INCH ROAD SUPER LITE SV 80MM 28/32-622/630
£14.95
Specifications
General
Model code
1138700
Model year
2027
Colour
Liquidbluegrid/Chrome
Weight (kg)
?
Gewicht van fiets in maat M zonder pedalen. Grote en kleine maten kunnen lichter of zwaarder zijn: kleine frames hebben vaak minder materiaal → lichter.
9.9
Frame and front fork
Frame
Aerium C:68X® Monocoque Advanced Twin Mold Technology, Twin Head Tube, Full Internal Cable Routing, Flat Mount Disc, 12x142mm, AXH
Front fork
?
There are both suspension and rigid forks. For extra comfort while cycling, a suspension fork is the best choice. The fork material also varies. It can be made of aluminum, a combination of aluminum and carbon, or completely carbon.
Cube Aerium C:68X®, Integrated Cable Routing, Flat Mount Disc, 12x100mm
Drivetrain and brakes
Number of gears
24
Rear derailleur
?
Brand and type of derailleur. The number of speeds indicates the number of sprockets.
Shimano Dura Ace Di2 RD-R9250-D, 12-Speed
Front derailleur
Shimano Dura Ace Di2 FD-R9250-F, Braze-On
Shifters
?
Make and type of gear levers.
Shimano Dura Ace Di2 SW-R9160 TT
Integrated shifters/brake levers
Shimano Dura Ace Di2 ST-R9180
Crankset
?
A crankset is the part of a bicycle that drives the pedals with the chain. It consists of cranks, chainrings and a bottom bracket.
Shimano Dura Ace FC-R9200, Hollowtech II, 54x40T, 4iiii Precision 3+ Powermeter dual side
Cassette
?
The set of gears on the back of the bicycle
Shimano Dura Ace CS-R9200, 11-30T
Chain
?
The bike can be driven in two ways; with a bike chain or with a belt drive. In the case of a belt it is always of the brand Gates.
Shimano CN-M9100
Brake system front
?
Brand, type of brake system and diameter of the brake disc.
Shimano Dura Ace BR-R9270, Hydr. Disc Brake, Flat Mount (140/140)
Brake system back
?
Brand, type of brake system and diameter of the brake disc.
Shimano Dura Ace BR-R9270, Hydr. Disc Brake, Flat Mount (140/140)
Cockpit
Headset
?
The bearing mechanism in the bicycle frame in which the front fork rotates, allowing you to steer smoothly.
Acros integrated, Top 1 1/8, Bottom 1 1/4
Handlebar
Cube Aerium C:68X® Cockpit System, XS-S LOW, M-L HIGH
Stem
Cube Aerium C:68X® Cockpit System, XS-S LOW, M-L HIGH
Front tire type, material and size where the first number is the width and the second number is the circumference in millimeters.
Continental Grand Prix 5000 TT TR, Kevlar, 28-622
Rear tyre
?
Rear tire type, material and size where the first number is the width and the second number is the circumference in millimeters.
Continental Grand Prix 5000 TT TR, Kevlar, 28-622
Other parts
Seat
Acid Athis
Seatpost
?
There are both sprung and fixed seatposts. For extra comfort while cycling, a sprung seatpost is the best choice.
Cube Aerium C:68 Aero
Lakstift
?
Een lakstift is een snelle manier om kleine krasjes en steenslag op je fiets te herstellen. Een lakstift wordt niet standaard meegeleverd bij de fiets. Bestel hem apart via het artikelnummer hier rechts aangegeven. Het kan voorkomen dat er (nog) geen lakstift beschikbaar is.
Geen lakstift beschikbaar / No touch-up paint kit available
