The perfect grip for any adventure. Our newly developed Newmen gravel bike handlebars offer a level of ergonomics and performance that is second to none. We worked closely with a biomechanic to develop the ergonomic shape, cross-sections and bends. With a downsweep and frontsweep of 4° each, a moderate flare of 12.5° and a reach of 75mm, it provides a natural hand position for maximum comfort on long gravel adventures and multi-day trips. Down- and frontsweep allow for a natural hand position even when your arms are narrower than shoulder width. The short reach leaves plenty of room for the forearms in the lower links. The cut-out on the drop (110mm) relieves pressure on the thumb joint and the drop-shaped design of the drop ensures a secure and comfortable grip in rough passages. In addition, we have kept the handlebars thinner in the drop so that you can fit a thicker, more comfortable handlebar tape without the handlebars becoming too thick.
The Advanced G Gravel dropbar is available in a range of widths (400-460mm) to suit your needs. The lightweight carbon gravel dropbar starts at 200 grams (400mm). Flexible cable routing also makes the carbon gravel handlebars extremely versatile: both internal routing through the stem (electronic shifting, two brake cables) and external routing in channels are possible with the Advanced G Gravel handlebars.
Attention!! Due to the oval shape of the drops it is not possible to mount the Shimano junction box EW RS910 for 11-speed Di2 into the barends.
SPECIFICATIONS NEWMEN DROPBAR ADVANCED SL GRAVEL 31.8 MM
- Reach: 75mm
- Drop: 110mm
- Flare: 12.5°
- Max. system weight: 130 kg
- Intended Use: Gravel
- Aerobar Compatible: no
- Di2 Compatible: yes
- 2-Bolt Stem Compatible: no
- Material: Carbon
- Bar Width: 400mm / 420mm / 440mm / 460mm
